Pentair – EC-520554 – IC20 IntelliChlor Replacement Salt Cell – Limited Warranty

The Pentair Salt Cell is made for use with the Pentair IntelliChlor IC20 Chlorine Generator system. Includes a 15 ft cable and sanitizes up to 20K gallon pool.

The Pentair IntelliChlor IC20 Replacement Salt Cell is designed to sanitize pools up to 20,000 gallons. The Pentair IntelliChlor IC20 Salt Cell includes a lengthy 15 foot UL-approved cable.
The IntelliChlor IC20 Salt Chlorinator automatically generates pure chlorine from the salt water that passes through the plates inside the cell. With a salt chlorinator, you are still sanitizing with chlorine but it is a more pure form of chlorine. This process of salt chlorination provides soft and silky smooth feeling swimming pool water. Using the IntelliChlor Salt Chlorinator provides sanitized safe water and a more comfortable swimming experience.

At the heart of this top-of-the-line chlorine generation system is the IntelliChlor cell. While most other big name salt chlorination systems use a power center equipped with a display to control the chlorination, the IntelliChlor cell features a control display right on the unit itself. The user-friendly functions found on the control display make monitoring chlorine output, water flow, salt levels and cell cleanliness an absolute breeze.

When it comes to durability and reliability, the IntelliChlor Chlorine Generator cell is simply unmatched. Each and every cell is built with titanium blades coated with ruthenium oxide, which is responsible for chlorine production. The salt cell comes with large threaded unions that make it easy to install or replace your existing cell. To top it off, the IntelliChlor cell features waterproof electronics so you won’t have to worry about leaks or other issues damaging the controls.
To help extend the life of the salt cell, be sure to inspect it every three months. Calcium can build up inside the plates over time and can hinder the performance of chlorine production in the cell. Use a salt cell acid washing kit (Pentair IntelliChlor Acid Washing Kit) to help make cleaning the cell quick and easy.

The Pentair IntelliChlor IC20 Replacement Salt Cell is one of the best choices for producing chlorine to keep your pool water clean and safe to enjoy.

Common Questions:

How much salt is required?

• The salt level is recommended to be between 3500 – 4000 PPM.

How often do I clean the cell?

• The cell should be inspected every three months and cleaned when needed.

Do I still need to shock my pool?

• Yes, salt systems are designed to maintain a 3 – 4 PPM chlorine residual.

California Residents WARNING: Cancer and Reproductive Harm –

Installation Type:	Residential
Product Type:	Salt Chlorinator
Warranty:	2-Year
Pool Type:	In Ground
Eco-Friendly:	YES
Manufacturer:	Pentair
Product Type:	Salt Cell
Salt System Type:	Salt Only Cells
UL-C US Certified:	YES
